Tire Type Mobile Jaw Crusher Station

Tire Type Mobile Jaw Crusher Station

Feeding size: ≤800mm

Processing capacity: 85-650t/h

Applied material: river pebbles, rocks (limestone, granite, basalt, diabase, andesite, etc.), ore tailings.

Email us: sell@hxjq.com

The Advantages and Description of Tire Type Mobile Jaw Crusher Station:

Tire type mobile jaw crusher station, which is also called Portable crusher, incorporates all the equipment together on one truck, which has high chassis, narrower body compared with other trucks,

which ensures the crushing plant can be easily transported on highways and moved to crushing sites, so it is able to achieve on-site crushing without material transporting from one place to another place.

mobile_crusher

The Performance Characteristics of Tire Type Mobile Jaw Crusher Station:

1. PE Series high-performance crusher.

2. The integration feeder and vibrating screen with crusher.

3. Belt conveyor under the screen. Vibrating screen and crusher integrated on-board.

4. Steering traction axis, convenient highway transportation and entry working site.

mobile_crusher

The Composition and Working Process of Tire Type Mobile Jaw Crusher Station:

The mobile crushing and screening plants are composed of primary crushing and screening station and secondary one, belt conveyor, etc. Every Mobile crushing station is an independent working unit, which can respectively assume their different responsibility, and the belt conveyer is responsible for material transmitting and piling up between each crushing station.

Technical Parameter

Model HX938HD86 HX1149HD98 HX1349HD110 HX1349HD125
Transportation Length(mm) 12600 13500 14500 15200
Transportation Width(mm) 2600 2700 2800 2900
Transportation Height(mm) 3870 4200 4450 4500
Maximum Length(mm) 12500 14000 16100 14700
Maximum Width(mm) 4100 4500 5100 5100
Maximum Height(mm) 4100 4900 5000 5300
Weight(t) 39 57 55 65
Tire Configuration Biax Fitted Triaxial Fitted Triaxial Fitted Triaxial Fitted
Jaw Crusher HD86 HD98 HD110 HD125
Maximum Feeding Size(mm) 500 550 660 800
Discharge Opening Size(mm) 50-150 75-175 100-200 125-225
Capacity(t/h) 85-275 110-350 215-510 280-650
Vibrating Model ZSW380×95 ZSW420×110 ZSW490×130 ZSW490×130
Main Belt Conveyor B800×8.5M B1000×9.5M B1000×11M B1200×11M
Side-opening Belt conveyor(Optional) B500×3M B650×3.5M B650×4M B650×4M
Genset(Optional) (kw) 200 250 270 400
Iron Separator (Optional) RCYD(C)-8 RCYD(C)-10 RCYD(C)-10 RCYD(C)-12
